HIMEL Molded Case Circuit Breaker (MCCB) 3P 25A 35kA Thermal-Magnetic HDM3S160M02531XX is designed for reliable industrial power distribution and circuit protection.
HIMEL Molded Case Circuit Breaker (MCCB) 3P 25A 35kA Thermal-Magnetic HDM3S160M02531XX
The HIMEL Molded Case Circuit Breaker (MCCB) 3P 25A 35kA Thermal-Magnetic HDM3S160M02531XX protects commercial and industrial electrical systems against overloads and short circuits. This 3 Pole (3P) MCCB delivers a 25A rated current, a 35kA breaking capacity, and a 160AF frame size for reliable power distribution.
The breaker features a thermal-magnetic trip unit, supports 400/415V AC at 50/60Hz, provides a 35kA service breaking capacity (Ics), and complies with IEC 60947-2 for dependable electrical protection.
HIMEL Molded Case Circuit Breaker (MCCB) 3P 25A 35kA Thermal-Magnetic HDM3S160M02531XX Key Features
- 3 Pole (3P) Molded Case Circuit Breaker (MCCB)
- 25A Rated Current
- 35kA Breaking Capacity (Icu)
- 35kA Service Breaking Capacity (Ics)
- 160AF Frame Size
- Thermal-Magnetic Trip Unit
- 400/415V AC Rated Voltage
- 1000V Rated Insulation Voltage
- 50/60Hz Operation
- Overload Protection
- Short-Circuit Protection
- Power Distribution Protection
- IEC 60947-2 Compliant
- TÜV Certified
HIMEL MCCB 3P 25A HDM3S160M02531XX Applications
- Main Power Distribution Panels
- Industrial Switchboards
- Commercial Buildings
- Electrical Distribution Systems
- Industrial Machinery
- Power Control Panels
- Manufacturing Facilities
- Electrical Protection Systems
HIMEL MCCB 3P 25A 35kA HDM3S160M02531XX Technical Specifications
| Brand | HIMEL |
| Series | HDM3S |
| Model | HDM3S160M02531XX |
| Product Type | Molded Case Circuit Breaker (MCCB) |
| Pole Configuration | 3 Pole (3P) |
| Frame Size | 160AF |
| Rated Current | 25A |
| Rated Voltage | 400/415V AC |
| Frequency | 50/60Hz |
| Breaking Capacity (Icu) | 35kA |
| Service Breaking Capacity (Ics) | 35kA |
| Rated Insulation Voltage | 1000V |
| Trip Unit Technology | Thermal-Magnetic |
| Mounting Type | Fixed |
| Protection Rating | IP20 |
| Standard | IEC 60947-2 |
| Certification | TÜV |
HIMEL MCCB HDM3S160M02531XX FAQ
What is this MCCB used for?
The HIMEL HDM3S160M02531XX protects industrial and commercial electrical systems against overloads and short circuits.
What is the rated current?
This MCCB delivers a rated current of 25A.
What is the breaking capacity?
The breaker provides both a 35kA breaking capacity (Icu) and a 35kA service breaking capacity (Ics).
Which standard does this MCCB comply with?
The breaker complies with IEC 60947-2 and carries TÜV certification.
For complete technical specifications, visit the HIMEL Official Website.
